Transformer insulation paper cutting machine



Machine uses:

Motor insulation paper cutting machinee is specially designed for cutting various insulation papers used in transformer, inductor, and motor manufacturing, such as transformer cardboard, cable paper, crepe paper, DDP paper, NOMEX paper, and other insulating materials.



Machine composition:

The electrical insulation paper cutting machineadopts a high-precision servo control system, enabling automatic feeding, fixed-length cutting, counting, and stacking. The machine features stable operation, smooth cutting edge, high precision, and high efficiency, making it ideal for mass production in coil winding and insulation processing workshops.

1. The insulating board cutting machine boasts high cutting precision and minimal length error.

2.The insulation material cutting machine features fast feeding speed and adjustable cutting length.

3. Operation is simple, with parameters set via a touchscreen.

4. The dielectric paper cutting machine is structurally stable, operates with low noise, and has a long service life.

5. The insulating paper slitting machine can accommodate insulating paper of various thicknesses and widths.

6. The insulation paper shearing machine can accommodate insulating paper of various thicknesses and widths.



 Technical parameters :

– Cutting speed: 80 meters/minute

– Cutter width: 0.1-800mm

– Cutting length: 0.1mm-99999.9mm

– Weight: 220kg

– Dimensions: 1480*1130*1200mm



Advantages:

• High cutting precision & stable dimension: The insulation material cutting machinee employs a dual control system of servo motor and encoder, ensuring minimal length error and consistent cutting of transformer insulation paper, thereby improving coil insulation quality.
• Wide application for various materials: The electrical equipment insulation paper cutter can cut various insulation materials such as cable paper, crepe paper, DDP paper, NOMEX paper, and transformer paperboard, making it a multi-purpose machine.
• High automation & improved efficiency: The dielectric paper cutting machine features automatic feeding, automatic length setting, automatic cutting, automatic counting, and automatic stacking, reducing manual intervention and making it suitable for mass production.
• Smooth cutting edge without burrs: The insulation paper shearing machine features a rationally designed cutter structure, adjustable pressure, and smooth cutting edges that do not damage the insulation layer or affect subsequent winding processes.
• Stable performance & low failure rate: The insulating paper slitting machine boasts a rigid frame, smooth transmission, low noise, and is resistant to wear during long-term continuous operation, resulting in low maintenance costs.
• Material saving & cost reduction: The transformer insulation paper cutting machine provides precise feeding with no waste, has a high cutting utilization rate, and can significantly reduce insulation paper loss with long-term use.
