TVOL-8060-15 Vertical Type APG Clamping Machine

Short Description:

TVOL-655vertical type APG machine is made up with:
-1. APG clamping machine frame
· Q235# 10mm thickness steel, machine more stably;
· release welding internal stress by heat treatment,
· lathe machine processing ensure high installation precision
-2. Power cabinet -Adopt reliable and general electrical elements, durable and easy maintain
-3. Vertical type design, more convenient to take out product.

Inquiry

Contact Us

    Category:

    TVOL-8050-15 Vertical Type APG Press Machine：

    singliemg
    sinfgleimg

    TVOL-8050-15 Vertical Type APG Press Machine working video:

    Application:

    Vertical type apg epoxy resin clamping machine is special machine for casting epoxy resin  bushings, insulator .especially suitable for casting epoxy resin bushing.

    singliemgApplication

    Advantages:

    -Integrated on machine→ easy installation,the user no need to hard work of connecting oil pipes and wires, just plug in the power supply directly.
    →save shipping cost,save factory space.
    Machine frame: Tempering and finish machinery →Improve strength,avoid deformation,ensure high precision,avoid mold leakage
    Safe fences→ avoid work injure
    Supply technical training→Ensure client make qualified products
    Supply complete production line→From machine,mold to raw material,assist client
    build production line in shortest time and reasonable cost.

    Technical Datas:

    Model No. TVOL-6050-15
    Heating plate size (mm） Clamping force(KN） Speed of clamping clos（m/min） Speed of clamping open（m/min） Distance of heating plates（mm）
    800X500 150 2.4 3.3 145-965mm
    Heating power (KW） Hydraulic unit power (KW） Tilting degree （°） Machine dimension (mm） Machine weight (KG)
    12 2.2 5° 2200*1020*3985 2950

    Vertical Type APG Machine At Client Site&Onsite Technical Training:

    We not only produce APG machine and molds,but also offer technical training at site,ensure client produce qualified products.

    Bushing producing by APG machine process:

    singim

    siingleimg

    Onsite Technical Training In Client Company:

    After X-ray, tensile test, partial discharge test, leakage test, the product meets customer requirements, and the customer is very satisfied.

    APG Press Machine Production Process:

    1.Milling machine frame: each side of frame will milled by vertical lathe machine,ensure installation precision,avoid mold leakage.
    2.Heating treatment for machine frame: Do 3 times of heat treatment for machine frame after welding. release inter stress,reduce machine get deformation.

    sing1gs

    APG Press Machine Delivery Process:

    After the qualified samples of the equipment and molds are prepared, we will carry out strict packaging to avoid damage to the equipment during transportation and smoothly deliver to the customer.

    packing
